3G 4G GSM Gate Opener Access Remote Control by Free Phone Call Home Alarm Systems Security for Automatic Door Opener RTU5024|remote access|remote access controlcontrol access -

Product Code: RTU5024

Availability: 2460

Available Options

2460 pieces available

GSM Alarm Gate Opener Remote Control Free Phone Call Alarm Systems Security Home for Automatic Door Opener Garage Defend RTU5024

The GSM Gate Opener RTU5024 is an powerful GSM Relay, it is a very simple device which can be used for authorized

door access, controlling gates, switching of remote equipment, car parking systems. Actually the GSM Relay Switch

RTU5024 can be used in places which require to turn ON/OFF your system, machines, equipment remotely with a

FREE call from your mobile phone.

1. Advantages

>  Quad-band, can work in the worldwide GSM Networks;

>  No call charges. the GSM GPRS Relay Switch rejects the call from authorized number then carries out the turn ON/OFF action on the first 'ring';

>  Multiple applications. (gates, bollards, barriers, garage doors, shutters and access doors or machines);

>  Secure - Using caller-ID for identification, unknown callers are ignored;

>  Can be operated from anywhere, no distance limit;

>  Add or remove users by SMS Text command;

>  No need to provide a remote control or keys for different users;

>  Up to 200 authorized phone numbers can be configured at the specified time;

>  One output with relay rating 3A/240VAC for connecting the switch of the door or machines;

>  The relay action will return a SMS confirmation to the owner or authorized call in number, this function is editable by user;

>  The relay close or open time is programmable;

>  Multiple applications. (gates, bollards, barriers, garage doors, shutters and access doors or machines);

Setting:

>  SMS command;

>  Operate from anywhere anytime, no distance limitation;

2. Applications:

>  Remote open/close swing/sliding gates, doors, shutters, garage doors,locks with a free call!

>Residential: Door,gate,garage access control, electronic fan,microwave,air-conditioner control.

>Industry:Remote switch equipment, for example: street lights, solar power, motor, inverter, PLC, pumps, fans, etc.

>Agriculture:Remote control pumps, etc.

>Business:Remote control electronic boxes,bright billboards,LED signs,etc.


GSM Frequency:Quad-band 850/900/1800/1900MHz
Digital Output:NC/NO dry contact, 3A/240VAC
DC Power supply:9~24VDC/2A
Power consumption:12V input Max. 50mA/Average 25mA
SIM Card:Support 3V SIM Card
Antenna:50ohm SMA Antenna interface
Temperature range:-20~+60 C degree
Humidity range:Relative humidity 90%
Exterior dimension:W102*D76*H27 mm
Net Weight:180 g

>   Gate Opener * 1

>  User Manual *1

without power adaptor,if need,pls buy from this link:

https://www.Safariis.com/item/32610893149.html?spm=2114.12010615.8148356.1.9f8a3bf8cekhwM





Aliexpress
Brand Name KING PIGEON
Certification FCC
Direction None
GSM Door Remote Control Apply for Swing gate, sliding door,garage door locks
GSM Door Remote Control Band 850/900/1800/1900MHz
GSM Door Remote Control Dimensions 102*76*27mm
GSM Door Remote Control Relay control free phone call, SMS commands
GSM Door Remote Control Relay rating 240V/3A, 24V/5A
GSM Door Remote Control Setting SMS commands
GSM Door Remote Other appliations Remote access control,wireless access control
Model Number RTU5024
Origin CN(Origin)
Power consumption Standby: 15mA, Relay close: 70mA
Rating power supply 9~24V DC 1~2A
Security Mode Fail Safe
White list/Authorized users 200
